PreSonus StudioLive 32.4.2AI Digital Mixer with FireWire Interface

With extensive DSP on all 32 channels and 4 buses, the 34.2.AI digital mixer represents the next generation in PreSonus' popular StudioLive console series.

StudioLive 32.4.2 AI Specs:

- Input Channels: 32
- Aux Buses: 18 (14 with analog outs + 4 internal FX)
- Mute Groups: 6
- Quick Scenes: 8
- Digital Sends/Returns: 48/34
- Fat Channel EQ: 4-band parametric with individual band and global On/Off
- Gate Parameters: On/Off, Threshold, Range, Attack, Release, Key Filter, Key Listen, and Expander
- Limiter Parameters: On/Off, Threshold
- Graphic EQ: 18 (auxes, mains); front-panel GEQ switch
- Dimensions (LxWxH): 21.31" (54.13 cm) x 31.58" (80.21 cm) x 7.02" (17.82 cm)
- Weight: 50 lbs. (22.68 kg)

Tech Specs for StudioLive AI Series:

Microphone Preamps (XLR Balanced):
- Type: XLR Female, Balanced
- Frequency Response to Direct Output: 20 Hz to 40 kHz +/-0.5 dBu
- Frequency Response to Main Output: 20 Hz to 20 kHz +/-0.5 dBu
- Input Impedance (Balanced): 1 kOhms
- THD to Direct Output: < 0.007%, +4 dBu, 20-20 kHz, unity gain, unwtd
- THD to Main Output: <0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd
- EIN to Direct Output: +125 dB unwtd, +130 dB A-wtd
- S/N Ratio to Direct Output: 105 dB
- S/N Ratio to Main Output: 94 dB
- Common Mode Rejection Ratio: 65 dB
- Gain Control Range: -15 dB to +65 dB (+/- 1 dB)
- Maximum Input Level (unity gain): +22 dBu
- Phantom Power: +48 VDC

Line Inputs:
- Type: 1/4" TRS Female, balanced mono
- Frequency Response to Direct Outputs: 10-40 kHz, 0 / -0.5 dBu
- Frequency Response to Main Outputs: 20-20 kHz, +/-0.5 dBu
- Input Impedance: 10 kOhms
- THD to Direct Output: <0.007%, +4 dBu, 20-20 kHz, unity gain, unwtd
- THD to Main Output: <0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd
- S/N Ratio to Direct Output: 105 dB
- S/N Ratio to Main Output: 94 dB
- Gain Control Range (+/-1 dB): -20 dB to +20 dB
- Maximum Input level (unity gain): +22 dBu

Tape Inputs:
- Type: RCA Female, unbalanced (stereo pair)
- Maximum Input Level: +22 dBu

Auxiliary Inputs:
- Type: 1/4" TRS Female, balanced (2 stereo pairs)
- Maximum Input Level: +22 dBu

Main Outputs:
- Type: Male, balanced (stereo pair); 1/4" TRS Female, balanced (stereo pair); XLR Male, balanced (mono)
- Rated Output Level: +24 dBu
- Output Impedance: 100Ohms

Aux Outputs:
- Type: 1/4" TRS Female, balanced (mono)
- Rated Output Level: +18 dBu
- Output Impedance: 100Ohms

Subgroup Outputs:
- Type: 1/4" TRS Female, balanced (mono)
- Rated Output Level: +18 dBu
- Output Impedance: 100Ohms

Tape Outputs:
- Type: RCA Female, unbalanced (stereo pair)
- Rated Output Level: +18 dBu
- Output Impedance: 100Ohms

Control Room Outputs:
Type: 1/4" TRS Female, balanced (stereo pair)
Rated Output Level: +18 dBu
Output Impedance: 100Ohms

System Crosstalk:
Input to Output (Ref = +4 dBu, 20 Hz-20 kHz, unwtd): -90 dBu
Adjacent Channels (Ref = +4 dBu, 20 Hz-20 kHz, unwtd): -87 dBu

Noise Gate / Expander:
- Threshold Range: -84 dB to 0 dB
- Attack Time: 0.02s to 500 ms / 0.5 ms
- Release Time: 0.05s to 2s
- Expander Attenuation Range: 2:1
- Gate Attenuation Range: -84 dB to 0 dB / infinity
- Key Listen Filter: 2nd-order resonant bandpass; Q=0.7; OFF, 40 Hz-16 kHz

Limiter:
- Threshold: -56 dB to 0 dB / -28 dBFS
- Ratio: infinity:1
- Attack: 20 ms
- Hold: 10 ms
- Release: 20 ms

Compressor:
- Threshold Range: -56 dB to 0 dB
- Ratio: 1:1 to 14:1
- Attack Time: 0.2 ms to 150 ms
- Release Time: 40 ms to 1000 ms
- Auto Attack and Release: Attack = 10 ms, Release = 150 ms
- Curve Types: hard and soft knee

Parametric EQ:
- Type: 2nd-order shelving filter (Q = 0.55)
- Low (Lowpass or Bandpass): 36 to 465 Hz, +/-15 dB
- Low Mid: 90 Hz to 1.2 kHz, +/-15 dB
- High Mid: 380 Hz to 5 kHz, +/-15 dB
- High (Highpass or Bandpass): 1.4 kHz to 18 kHz, +/-15 dB
- Q: 0.1 to 4 / 16.4.2AI*: Low Q=0.55, Hi Q=2.0

Graphic EQ:
- 31-Band 1/3rd Octave Controls: Curve-fitting algorithm
- Gain/Attenuation: +/-15 dB

Digital Audio:
- ADC Dynamic Range (A-wtd, 48 kHz): 118 dB
- DAC Dynamic Range (A-wtd, 48 kHz): 118 dB
- FireWire: s800, 800 Mb/s
- Internal Processing: 32-bit, floating point
- Sampling Rate: 44.1, 48 kHz
- A/D/A Bit Depth: 24
- Reference Level for 0 dBFS: +18 dBu

Clock:
- Jitter: <20 ps RMS (20 Hz - 20 kHz)
- Jitter Attenuation: >60 dB (1 ns in = 1 ps out)

Power/Environmental:
- Connector: IEC
- Input-Voltage Range: 100 to 230V, 50-60 Hz
- Power Requirements: 200W
- Temperature Range: 0 to 40 degrees Celsius / 32 to 104 degrees Fahrenheit

Computer system requirements for Virtual StudioLive-AI:

Mac:
- Mac OS X 10.7.5 or later
- Intel Core Duo processor (Intel Core 2 Duo or Core i3 or better recommended)
- 4 GB RAM (more recommended)

Windows:
- Windows 7 x64/x86 SP1, Windows 8 x64/x86
- Intel Core Duo or AMD Athlon X2 processor (Intel Core 2 Duo or AMD Athlon X4 or better recommended)
- 4 GB RAM (more recommended)

Mac and Windows Systems:
- FireWire S800 (IEEE 1394b) port
- Ethernet port recommended
- Internet connection recommended
- DVD-ROM drive
- Internal or external 7200 RPM storage drive highly recommended
- Monitor with 1280x800 resolution

The minimum system requirements may differ for DAWs other than Studio One. Please check the requirements for your DAW of choice with its manufacturer.

Note that the speed of your processor, amount of RAM and size and speed of your hard drive will greatly affect the overall performance of your recording system. Also, a more powerful system (faster processor with more RAM) will allow for lower latency (signal delay) than you might experience while monitoring audio or MIDI signals. Monitor resolution for both PC and Mac should be no lower than 1280x800 pixels. Known compatible and incompatible hardware

Weight, Dimensions, and Manufacturer Part Numbers

Base Item

Shipping Weight: 70 lbs

Shipping Dimensions: 38 x 32 x 13 in

Manufacturer Part Number (MPN): SLM32.4.2AI

with Recording Pack

Shipping Weight: 193 lbs
