QSC GX5 Power Amplifier

Features:

- 2 x balanced XLR and 1/4-inch TRS (one on each channel)
- RCA phono connectors
- Speakon combo XLR/TRS connectors (on each channel)
- 2-pole and 4-pole plugs
- Positive/negative binding posts
- 100 Hz LF/HF Crossover switch
- GuardRail Heat and Peak limiting system
- Clipping monitor LED light
- All-steel chassis
Output watts per channel:
- 8 Ohms / both channels driven: 500 Watts
- 8 Ohms / single channel driven: 600 Watts
- 4 Ohms / both channels driven: 700 Watts
- 4 Ohms / single channel driven: 850 Watts

- Signal to Noise (20 Hz - 20 kHz): 100 dB
- Input Sensitivity: 1.2 Vrms
- Voltage Gain (8 Ohms): 34.4 dB
- Output Circuitry: 2-tier Class H
- Power Requirements: 6A
- Frequency Response: 20 Hz - 20 kHz, +0, 1 dB
- Dynamic Headroom (4 Ohms): 2 dB
- Damping Factor: 100
- Input Impedance: Greater than 20k (balanced)
- Maximum Input Level: +24 dB (16 Vrms)
- Input Connectors (each channel): 3-pin XLR and 1/4-inch TRS, balanced, parallel Phono, unbalanced
- Output Connectors (each channel): Speakon, 1/4-inch, Binding Posts
- Amplifier and Load Protection: Short circuit, open circuit, thermal, RF protection Load protected against DC faults
- Rear Panel Controls: Full Range / Crossover switch
- Dimensions (H x W x D): 3.5 x 19 x 10.1 inches (89 mm x 483 mm x 257 mm)
- Weight: 26 lbs (12 kg)

Front Panel Controls and Indicators:
- Gain controls, 21 detents
- Red Clip LEDs, proportional, 0.1% THD threshold
- Green Signal LEDs, threshold -35 dB
- Blue Power LED, AC on

Distortion:
- 8 Ohms: less than 0.05%
- 4 Ohms: less than 0.1%

Weight, Dimensions, and Manufacturer Part Numbers

Base Item

Shipping Weight: 31 lbs

Shipping Dimensions: 24 x 14 x 7 in

Manufacturer Part Number (MPN): GX5120V
